Description
| SPECIAL NOTES | Prior to installation, verify all hardware and properly tighten and spring preload is set to 5-10mm(1/4-3/8in). Our technical department is available to answer any other questions. *Requires welding factory spindles onto the lower front brackets. Make sure your E34 has 61MM Front Axle Clamp |
|---|---|
| DAMPING LEVELS | 16 Levels |
| HEIGHT ADJUSTMENT | Yes |
| SPRING RATE(FRONT) | 8 kg/mm |
| SPRING RATE(REAR) | 6 kg/mm |
| SPRING LENGTH(FRONT) | 180 mm |
| SPRING LENGTH(REAR) | 200 mm |
| CAMBER PLATE(FRONT) | Yes, With Pillow Ball |
| CAMBER PLATE(REAR) | No |
| SPRING INNER DIAMETER(FRONT) | 62 mm (2.44 inch) |
| SPRING INNER DIAMETER(REAR) | 62 mm (2.44 inch) |
